![]() Wheel Diameter |
![]() Width of Tread |
![]() Size of Plate |
![]() Plate hole centers |
![]() Plate hole |
![]() Overall height |
![]() Load capacity |
number |
---|---|---|---|---|---|---|---|
125 | 50 | 105x80 | 80x60 | 13.5x11 | 170 | 700 | 23P1F125B50BPHDX6020 |
150 | 50 | 135x110 | 105x80 | 13.5x11 | 200 | 800 | 23P1F150B50BPHDX6020 |
160 | 50 | 135x110 | 105x80 | 13.5x11 | 205 | 800 | 23P1F160B50BPHDX6020 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 245 | 800 | 23P1F200B50BPHDX6020 |
Swivel head with tapered roller bearing and axial ball bearing,welded steel fork., White injection polyamide,two ball bearings
