Housing
fixed_castors
Wheel diameter
260mm
Load capacity
70kg
Temperature
- 20 / + 60 °C
Standard
EN 12532
WarrantyHardness of tread
Shore A 85
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, red polyopylene wheel centre, yellow foam polyurethane thread, roller bearing
 Wheel Diameter |
 Width of Tread |
 Size of Plate |
 Plate hole centers |
 Plate hole |
 Overall height |
 Load capacity |
number |
|---|---|---|---|---|---|---|---|
| 260 | 80 | 230x125 | 190x75 | ф14 | 295 | 70 | 08P1F260E80FPTRX7520 |
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, red polyopylene wheel centre, yellow foam polyurethane thread, roller bearing
Tile Floor
Resin Cement Floor
