Wheel Diameter |
Width of Tread |
Size of Plate |
Plate hole centers |
Plate hole |
Overall height |
Load capacity |
number |
---|---|---|---|---|---|---|---|
100 | 38 | 105x80 | 80x60 | 11X9 | 132 | 350 | 09P1F100B38BPHDX4015 |
125 | 38 | 105x80 | 80x60 | 11X9 | 155 | 350 | 09P1F125B38BPHDX |
160 | 50 | 135x110 | 105x80 | 13.5x11 | 190 | 500 | 09P1F160B50BPHDX6020 |
160 | 50 | 135x110 | 105x80 | 13.5x11 | 200 | 500 | 09P1F/S160B50BPHDX6020 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 235 | 500 | 09P1F200B50BPHDX6020 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 245 | 600 | 09P1F/S200B50BPHDX6020 |
Pressed steel swivel fork, zinc-plated double ball race ,sealed in the swviel head, white injection polyamide, two ball bearings
