Wheel Diameter |
Width of Tread |
Size of Plate |
Plate hole centers |
Plate hole |
Overall height |
Load capacity |
number |
---|---|---|---|---|---|---|---|
80 | 30 | 102x87 | 80x60 | 11X9 | 100 | 50 | 07P1F80D30JGMRX4012 |
100 | 30 | 102x87 | 80x60 | 11X9 | 125 | 70 | 07P1F100D30JGMRX4012 |
100 | 30 | 102x87 | 80x60 | 11X9 | 128 | 70 | 07P1F/S100D30JGMRX4012 |
125 | 37.5 | 102x87 | 80x60 | 11X9 | 155 | 100 | 07P1F125D37.5JGMRX6020 |
160 | 40 | 135x114 | 105x80 | 13.5x11 | 190 | 140 | 07P1F160D40JGMRX6020 |
200 | 50 | 135x114 | 105x80 | 13.5x11 | 235 | 205 | 07P1F200D50JGMRX6020 |
Pressed steel swivel fork assembly, zinc-plated swivel head with double ball race, grey 85+/-3 solid rubber tread, pressed steel wheel centre, roller bearing
