Housing
fixed_castors
Wheel diameter
100, 125mm
Load capacity
300, 350kg
Temperature
- 20 / + 60 °C
Standard
EN 12532
WarrantyHardness of tread
Shore A 92
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, silvery casting-aluminium wheel centre, shore a 92 brown polyurethane tread,two ball bearings
 Wheel Diameter |
 Width of Tread |
 Size of Plate |
 Plate hole centers |
 Plate hole |
 Overall height |
 Load capacity |
number |
|---|---|---|---|---|---|---|---|
| 100 | 38 | 135x110 | 105x80 | 13.5X11 | 128 | 300 | 06P1F100K38CUIDX4515 |
| 125 | 38 | 135x110 | 105x80 | 13.5X11 | 155 | 350 | 06P1F125K38CUIDX4515 |
| 125 | 38 | 135x110 | 105x80 | 13.5X11 | 155 | 350 | 06P1F/S125K38CUIDX4515 |
Tile Floor
Resin Cement Floor
