Wheel Diameter |
Width of Tread |
Size of Plate |
Plate hole centers |
Plate hole |
Overall height |
Load capacity |
number |
---|---|---|---|---|---|---|---|
80 | 36 | 102x87 | 80x60 | 11X9 | 100 | 130 | 07P1F80A36CEPBA4208 |
100 | 36 | 102x87 | 80x60 | 11X9 | 125 | 160 | 07P1F100A36CEPBA4208 |
100 | 36 | 102x87 | 80x60 | 11X9 | 128 | 160 | 07P1F/S100A36CEPBA4208 |
125 | 36 | 102x87 | 80x60 | 11X9 | 155 | 230 | 07P1F125A36CEPBA5210 |
125 | 38 | 102x87 | 80x60 | 11X9 | 155 | 250 | 07P1F125A38CEPBA5210 |
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, black polyamide wheel centre, shore a 68+5 blue elastic rubber tread, central ball bearing,black samll plastic thread guards
