Wheel Diameter |
Width of Tread |
Size of Plate |
Plate hole centers |
Plate hole |
Overall height |
Load capacity |
number |
---|---|---|---|---|---|---|---|
160 | 50 | 135x110 | 105x80 | 13.5x11 | 190 | 400 | 09P1F160C50CESDX5425 |
160 | 50 | 135x110 | 105x80 | 13.5x11 | 200 | 400 | 09P1F/S160C50CESDX5425 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 235 | 450 | 09P1F200C50CESDX5420 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 245 | 450 | 09P1F/S200C50CESDX5420 |
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, black welded pressed steel wheel centre, 68+5 shore a 68+5 black elastic rubber tread, two ball bearings
