White Polyamide Heavy Duty Swivel Castors White Polyamide Heavy Duty Swivel Castors
White Polyamide Heavy Duty Swivel Castors White Polyamide Heavy Duty Swivel Castors
White Polyamide Heavy Duty Swivel Castors White Polyamide Heavy Duty Swivel Castors

White Polyamide Heavy Duty Swivel Castors

Heavy Duty Industrial Castors , White

Housing

swivel_castors

Wheel diameter

100, 125, 150, 160, 200mm

Load capacity

350, 700, 800, 800, 800kg

Temperature

- 20 / + 60 °C

Standard

EN 12532

WarrantyHardness of tread

Shore A 92

Description

Pressed steel fork,zinc-plated hardened and sealed double ball race without central king pin, white injection polyamide, two ball bearings

Chat Now

TECHNICAL DATA


Wheel Diameter

Width of Tread

Size of Plate

Plate hole centers

Plate hole

Offset
Overall height

Load capacity
number
100 38 105x80 80x60 11X9 40 130 350 03P1S100B38BPHDX5015
125 50 135x110 105x80 13.5x11 50 178 700 03P1S125B50BPHDX6020
150 50 135x110 105x80 13.5x11 53 210 800 03P1S150B50BPHDX6020
160 50 135x110 105x80 13.5x11 53 215 800 03P1S160B50BPHDX6020
200 50 135x110 105x80 13.5x11 55 245 800 03P1S200B50BPHDX6020


Pressed steel fork,zinc-plated hardened and sealed double ball race without central king pin, white injection polyamide, two ball bearings

Suitable Floor
Tile Floor

Tile Floor

Resin Cement Floor

Resin Cement Floor

Quality & Service since 18 Year

Our quality is creating an easier work-life for the user of the wheel.

Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
