Wheel Diameter |
Width of Tread |
Size of Plate |
Plate hole centers |
Plate hole |
Offset |
Swivel radius |
Overall height |
Load capacity |
number |
---|---|---|---|---|---|---|---|---|---|
80 | 32 | 105x80 | 80x60 | 11x9 | 36 | 129 | 100 | 100 | 07P1TB80D32CTPRX4012 |
100 | 32 | 105x80 | 80x60 | 11x9 | 40 | 132 | 125 | 100 | 07P1TB80D32CTPRX4012 |
100 | 32 | 105x80 | 80x60 | 11x9 | 40 | 132 | 128 | 100 | 07P1TB/S100D32CTPRX4012 |
125 | 32 | 105x80 | 80x60 | 11x9 | 40 | 134 | 155 | 150 | 07P1TB125D32CTERX5015 |
160 | 40 | 135x110 | 105x80 | 13.5x11 | 60 | 203 | 190 | 200 | 07P1TB160D40CTERX6020 |
200 | 40 | 135x110 | 105x80 | 13.5x11 | 60 | 203 | 235 | 220 | 07P1TB200D40CTERX6020 |
