![]() Wheel Diameter |
![]() Width of Tread |
![]() Size of Plate |
![]() Plate hole centers |
![]() Plate hole |
![]() Offset |
![]() Swivel radius |
![]() Overall height |
![]() Load capacity |
number |
---|---|---|---|---|---|---|---|---|---|
80 | 30 | 105x80 | 80x60 | 11x9 | 36 | 129 | 100 | 50 | 07P1TB80C30JCMRX4012 |
100 | 30 | 105x80 | 80x60 | 11x9 | 40 | 132 | 125 | 70 | 07P1TB100C30JCMRX4012 |
125 | 37.5 | 105x80 | 80x60 | 11x9 | 40 | 134 | 155 | 100 | 07P1TB125C37.5JCMRX5015 |
160 | 40 | 135x110 | 105x80 | 13.5x11 | 60 | 203 | 190 | 140 | 07P1TB160C40JCMRX6020 |
200 | 50 | 135x110 | 105x80 | 13.5x11 | 60 | 203 | 235 | 205 | 07P1TB200C50JCMRX6020 |
