 Wheel Diameter |
 Width of Tread |
 Size of Plate |
 Plate hole centers |
 Plate hole |
 Overall height |
 Load capacity |
number |
|---|---|---|---|---|---|---|---|
| 80 | 34 | 102x87 | 80x60 | 11X9 | 100 | 150 | 07P1F80H34DUPBA428 |
| 100 | 34 | 102x87 | 80x60 | 11X9 | 125 | 180 | 07P1F100H34DUPBA428 |
| 100 | 34 | 102x87 | 80x60 | 11X9 | 128 | 180 | 07P1F/S100H34DUPBA428 |
| 125 | 36 | 102x87 | 80x60 | 11X9 | 155 | 250 | 07P1F125H36DUPBA5210 |
Pressed steel swivel fork , zinc-plated double ball race ,sealed in the swviel head, grey polyamide wheel centre, shore a 92 green injection polyurethane tread, central ball bearing, green plastic samll thread guards
