Blue Elastic Rubber Fixed Castor with Two Ball Bearings

Blue Elastic Rubber Fixed Castor with Two Ball Bearings

Industrial Castors , Blue

Housing

fixed_castors

Wheel diameter

80, 100, 125, 160, 160，200，200mm

Load capacity

150, 180, 230, 350, 350, 400, 400kg

Temperature

- 20 / + 60 °C

Standard

EN 12532

WarrantyHardness of tread

Shore A 68+5

Description

Pressed steel swivel fork , zinc-plated, double ball race ,sealed in the swviel head, black polyamide wheel centre shore a 68+5 blue elastic rubber tread, two ball bearings

Chat Now

TECHNICAL DATA

Wheel Diameter	Width of Tread	Size of Plate	Plate hole centers	Plate hole	Overall height	Load capacity	number
80	36	105x80	80x60	11X9	108	150	09P1F80A36CEPDX4015
100	36	105x80	80x60	11X9	132	180	09P1F100A36CEPDX4015
125	36	105x80	80x60	11X9	155	230	09P1F125A36CEPDX5015
160	50	135x110	105x80	13.5x11	190	350	09P1F160A50CEPDX6020
160	50	135x110	105x80	13.5x11	200	350	09P1F/S160A50CEPDX6020
200	50	135x110	105x80	13.5x11	235	400	09P1F200A50CEPDX6020
200	50	135x110	105x80	13.5x11	245	400	09P1F/S200A50CEPDX6020

Pressed steel swivel fork , zinc-plated, double ball race ,sealed in the swviel head, black polyamide wheel centre shore a 68+5 blue elastic rubber tread, two ball bearings
