 Wheel Diameter |
 Width of Tread |
 Size of Plate |
 Plate hole centers |
 Plate hole |
 Offset |
 Swivel radius |
 Overall height |
 Load capacity |
number |
|---|---|---|---|---|---|---|---|---|---|
| 75 | 28 | 77x67 | 55.7x46.5 | 16x8.5 | 30.5 | - | 103 | 75 | 18P1TB75D28CCPPX3612 |
| 75 | 28 | - | - | - | 30.5 | - | 103 | 75 | 18P1TB/S75D28CCPPX3612 |
| 100 | 32 | 77x67 | 55.7x46.5 | 16x8.5 | 40 | - | 137 | 100 | 18P1TB100D32CCPPX3612 |
| 100 | 32 | - | - | - | 40 | - | 137 | 100 | 18P1TB/S100D32CCPPX3612 |
| 125 | 32 | 77x67 | 55.7x46.5 | 16x8.5 | 43 | - | 162 | 100 | 18P1TB125D32CCPPX3612 |
| 125 | 32 | - | - | - | 43 | - | 162 | 100 | 18P1TB/S125D32CCPPX3612 |
